Head Range | Up to 28 Meters |
Discharge Range | Up to 2700 LPH |
Power Rating | 0.37 kW (0.5 HP) |
Pressure Range | Up to 2.4 kg/cm2 |
Voltage range | 180 to 260 Volts (Single phase) |
Insulation | B Class |
Protection | IP 44 |
High Suction Lift: The pump has suction lift capacity of up to 7.5 metres with high head, facilitating pumping of water at high volumes for a variety of applications..
High Quality Aluminium Motor Body: Special grade aluminium motor body ensures high resistance to corrosion, better heat dissipation and lowers the pump’s overall weight for great portability.
TOP – Thermal Overload Protector: The pump set features a Thermal Overload Protector that protects the motor from overloading, shielding of the motor and associated circuit from the effects of fault current.
Handle to Enhance Grip and Portability: A handle attached to the pump allows user to carry the pump anywhere, adding to its portability and convenience of use.
Easy Maintainable Designs: Easy maintainable design and better interchangeability of components ensures that the pump can be serviced even at remote locations by semi-skilled technicians.
Shielded Ball Bearing: The low noise pumps are fitted with shielded ball bearing; so, no external lubrication is required throughout the life cycle.
High Efficiency and Energy Saving Design: Innovative design manufactured at state of the art, plant ensures optimum efficiency and lower energy consumption resulting in significant cost savings.
Dynamically Balanced Rotating Parts: Minimum vibration protect components from damage during the operation, thus ensuring consistent performance as concentricity is maintained.
