AARNA II

[offer_percentage]

All Taxes Included

0.5 HP MINI RANGE

Technical Specifications

Head Range 6 to 21 Meters
Capacity Range 1980 to 680 LPH
Power Rating 0.37 kW / 0.5 HP
Phase Single
Voltage Range 180 to 260 Volts
Insulation B CLASS

Impeller Brass
Delivery Casing Cast Iron
Motor Body Aluminium
Pump Shaft Carbon Steel
Cover NDE Aluminium
Seal Carbon Vs Ceramic

  • Water supply to overhead tanks in bungalows
  • Gardens/ fountains
  • Feed water to RO plants
  • Domestic water supply
  • Construction site
  • Home pressure boosting
  • Car Washing
  • Lawn sprinklers

Cathodic Electro Deposition (CED) Coating: CED is the latest coating technology for corrosion resistance with a uniform coating. It provides 5 times more protection over conventional painting, resulting in longer life. All major CI parts of Kirloskar pumps coming in contact with the water are CED coated.

Advanced Electrical Design: Lesser current for same output (compared to any other similar products)

Wide Voltage Range Operability: The motor is designed to withstand wide voltage variation from 180 to 260 volts and reduces chances of motor burning due to low / high voltage.

Lightweight and Compact Design: It allows users to carry the pump anywhere with ease, adding to its portability and convenience of use.

High Suction Lift: The pump has a suction lift capacity of up to 7.5 meters.

Enhanced Safety Features: All electrical parts of the pump are covered, which makes it safer to use.

Dynamically Balanced Rotating Parts: Minimum vibration protect components from damage during the operation, thus ensuring consistent performance as concentricity is maintained.

TOP – Thermal Overload Protector: The pump set features a Thermal Overload Protector that protects the motor from overloading, shielding of the motor and associated circuit from the effects of fault current.

Shielded Ball Bearing: The pumps are fitted with shielded ball bearings, which results in low noise level and so no external lubrication is required throughout the life cycle.
