Head Range | 6 to 21 Meters |
Capacity Range | 1980 to 680 LPH |
Power Rating | 0.37 kW / 0.5 HP |
Phase | Single |
Voltage Range | 180 to 260 Volts |
Insulation | B CLASS |
Impeller | Brass |
Delivery Casing | Cast Iron |
Motor Body | Aluminium |
Pump Shaft | Carbon Steel |
Cover NDE | Aluminium |
Seal | Carbon Vs Ceramic |
Cathodic Electro Deposition (CED) Coating: CED is the latest coating technology for corrosion resistance with a uniform coating. It provides 5 times more protection over conventional painting, resulting in longer life. All major CI parts of Kirloskar pumps coming in contact with the water are CED coated.
Advanced Electrical Design: Lesser current for same output (compared to any other similar products)
Wide Voltage Range Operability: The motor is designed to withstand wide voltage variation from 180 to 260 volts and reduces chances of motor burning due to low / high voltage.
Lightweight and Compact Design: It allows users to carry the pump anywhere with ease, adding to its portability and convenience of use.
High Suction Lift: The pump has a suction lift capacity of up to 7.5 meters.
Enhanced Safety Features: All electrical parts of the pump are covered, which makes it safer to use.
Dynamically Balanced Rotating Parts: Minimum vibration protect components from damage during the operation, thus ensuring consistent performance as concentricity is maintained.
TOP – Thermal Overload Protector: The pump set features a Thermal Overload Protector that protects the motor from overloading, shielding of the motor and associated circuit from the effects of fault current.
Shielded Ball Bearing: The pumps are fitted with shielded ball bearings, which results in low noise level and so no external lubrication is required throughout the life cycle.
